In the future CamFollowerJS will implement export in STL format for 3d printing. Nonlinear Passive Cam-Based Springs for Powered Ankle Prostheses visual editing of cam profile using mouseĪutomata resources (books, links.): look.Things I would like to add in the future:
Bad tracking of contact point in upper chart when follower does not pass throuogh cam center.Note: current version does not perform any check on output, so resulting cams could be impossible to realize in practice. The page loads the flat cartesian profile of the cam, and turns it into a circular/polar profile, the it starts rotating the cam as per aramters specified in the file itself (direction and speed) and shows how a follower follows the cam profile. The cam can be started from scratch, or loaded from an existing file, edited and saved again. This page allows creating cam profiles for cam/follower mechanisms used in automata. This page can work also offline on your PC, just download all the. Generator and simulator of cams profiles for cam/follower mechanisms.
